BRIGHT BEER TANK

BRIGHT BEER TANK - Image 2

BRIGHT BEER TANK

Bright Beer Tank with dished roof and bottom with high exchange efficiency cooling jacket

Cylinder and conical bottom and fully insulated to minimize thermal dispersions.

The particular shape of the tank favors the clarification and maturation of the beer and subsequent bottling.

PED certificates. Working pressure: 3 bar

Technical Features

Discover the productions

Request a quote

Category: BEER INDUSTRY

Table
Scheda tecnica

Table

Nominal CAPACITY [LT.]	DIMENSIONS [mm]
	Tank DIAMETER int/ext D_i/ D_e	HEIGHT						LEGS	TOT
		TOP T	Cylinder HC	Jacket HTC	Inner bottom F				Ht
						n°	G
						n°	G			650	820/920	164	1250	750	164	4	580		2188
1.000	980/1080	196	1250	970	196	4	600		2252
1.250	980/1080	196	1750	1220	196	4	600		2752
2.000	1194/1294	239	1750	1220	239	4	640		2838
2.500	1194/1294	239	2250	1470	239	4	640		3338
3.000	1433/1533	287	2250	1470	287	4	700		3434
4.000	1433/1533	287	2500	1470	287	4	700		3684
5.000	1592/1692	318	2500	1470	318	4	720		3746
6.000	1750/1850	350	2500	1940	350	4	750		3810
8.000	1750/1850	350	3250	2220	350	4	750		4560
10.000	2000/2100	400	3000	2220	400	4	800		4410
12.000	2000/2100	440	3750	2220	440	4	840		5240
